Algo 8305 Multi-Interface IP Paging Adapter
Algo 8305 Multi-Interface IP Paging Adapter
The Algo 8305 is the paging adapter for older PA systems that don't have a simple line input. It registers with your PBX as a SIP extension and gives you three ways to connect to the paging system: a phone port, an 8 Ohm output and a line output.
The phone port plugs into the paging system's talk battery input, the jack an old administrative phone or FXO port used to plug into. The 8305 acts like that phone going off-hook, so it can also pass DTMF tones to select zones on a legacy zone controller. The 8 Ohm output drives self-amplified speakers directly, and the line output feeds a standard amplifier.
If your amplifier just needs a line-level input, the Algo 8301 does that job and adds a bell scheduler.
Specifications
| Connects to | Your PBX as a SIP extension, and a paging system by phone port, 8 Ohm output or line out |
|---|---|
| Power | PoE 802.3af Class 0, 4 W max |
| SIP extensions | 50 page, 10 emergency alert |
| Phone port | RJ11, emulates an analog phone into a talk battery input (loop start, DTMF) |
| 8 Ohm output | Balanced output for self-amplified speakers, 2 kOhm down to 8 Ohm total load |
| Line out | Balanced, isolated output to an amplifier |
| Other I/O | Relay input and output, 3.5mm aux out |
| Environment | Indoor, 32 to 104 F |
| Dimensions | 6.75" x 4.3" x 1.18" |
| Manufacturer part # | 8305 |
| UPC | 628123910039 |
Good to know
- Registers with your phone system as a standard SIP extension, so it works with most on-premise and hosted PBXs.
- Pick the port that matches your amplifier's input before you buy. Algo publishes an integration guide on the 8305 product page.
What's in the box
- Algo 8305 paging adapter
- Snap mounting bracket
Warranty and support
Algo products carry the manufacturer's warranty, and we handle the claim with the distributor for you. Questions before you buy? Email shop@crosstalksolutions.com or call 541-787-8870.
